AM0010-2
5
6
7
8
9
10
11
BW100 Belt Weigher [if tted]
11. SPAN REQUIRED.
10. PRESS TO RETURN TO RUN MODE.
8. DEVIATION.
9. NEW ZERO COUNT CALIBRATION
COMPLETE - RETURN TO RUN MODE.
7. FREQUENCY COUNT DISPLAYED DURING
CALIBRATION.
6. INITIAL ZERO COUNT.
5. ZERO CALIBRATION REQUIRED.
ROUTINE CALIBRATION SIMPLIFIED GUIDE
1. The Following procedures may be performed on a routine basis as required.
2. Important: The belt should be stopped and secured prior to suspending or removing the test weights for
span calibration.
3. Safe working practice should be adopted at all times.
Zero Calibration
4. With belt running empty at normal speed with test weights removed.
To Next Page
