Correction Factor
Correction factor for
injection mode
0.5 – 2.0
1
29
SRC Volume
(cc)
The Volume of the SRC
chamber in CCs
1000 - 2000
1171
30
SRC Area
(cm
2
)
The measuring Area of
the SRC Chamber
50 - 100
78
31
CPY Volume
(cc)
The Volume of the CPY
chamber in ccs
1000 - 5000
2427
32
CPY Area
(cm
2
)
The measuring Area of
the CPY Chamber
150 - 200
167
33
Chamber Air Temperature
(
o
C)
Chamber Air
Temperature in degrees
Celcius
0 - 50
20
34
Ship Mode
Used to prevent power
turning on, Must have
external power to exit
mode
0 = Normal
1=shipmode
0
35
Probe 1 Function
Select the functionality of
probe 1 port. I2C, Analog,
or SDI-12
0= I2C
1= PAR2
2=SoilTemp
3=SoilMoist
4=NewProbe
0
36
Wi-Fi Power
Turns the Wi-Fi Power on
/ off
0 = OFF
1 = ON
0
37
Probe 2 Function
Select the functionality of
probe 2 port. I2C, Analog,
or SDI-12
n/a
n/a
38
Flow Rate
Not used in TARGAS
n/a
n/a
39
SUPPLY_FLOW
PLC flow
200 - 400
250
40
SAMPLE_FLOW
Analysis flow
50 - 200
150
41
CO2_DUTY_CYCLE
Percent time at ambient
0 -100
100
42
H2O_DUTY_CYCLE
Percent time at ambient
0 -100
100
43
MEASURE_MODE_GCAM
What type of IRGA
reading
0 = Last
1 = Average
2 = Project
2
44
DIFF_MEASURE
How the TARGAS is
configured to do
measurements.
0 = Diff
1 = Ref
2 = An
3 = Zero
0
45
CO2_REF_DELAY
Time when measurement
is read after valve switch
0.1 - 6.0
1.1
46
H2O_REF_DELAY
Time when measurement
is read after valve switch
0.1 - 6.0
2.7
47
CO2_AN_DELAY
Time when measurement
is read after valve switch
0.1 - 6.0
1.1
48
H2O_AN_DELAY
Time when measurement
is read after valve switch
0.1 - 6.0
2.7
