Incorrect calibration

Cell constant, valid range: 0.005 ... 15 1/cm

An error message appears if the result of the calibration lies outside the speci‐

fied tolerance limits. In this case, the current calibration is not carried over.

Check the prerequisites for calibration and eliminate the error. Then repeat cali‐

bration.
