ProMinent DULCOMETER diaLog DACb User Manual

12.2 Setting limit values channel 1
Continuous display ➨ ➨ or [Limit values] ➨ [Limit values] ➨ or
[Limit value channel 1] ➨ [Limit value channel 1]
Limit values ch. 1
Limit value 1
A1012
4.1.5
Limit value 2
System response / hysteresis
Fig. 94: Setting limit values channel 1
12.2.1 Setting [Limit 1]
Continuous display ➨
➨ or
[Limit values] ➨ [Limit values] ➨ or
[Limit value channel 1] ➨ [Limit ch. 1] ➨
or [Limit ch. 1] ➨ [Limit 1]
Limit 1
Function
Low limit
A1013
4.1.1.4
Value 6,00 pH
ON delay
OFF delay
No relays assigned!
Please assign in <Relays> menu.
Fig. 95: Setting Limit 1
12.2.2 Setting [Limit 2]
Continuous display ➨
➨ or
[Limit values] ➨ [Limit values] ➨ or
[Limit value channel 1] ➨
[Limit value channel 1] ➨ or [Limit 2] ➨
[Limit 2]
Setting the [Limit values]
141
