14 Setting the [Relays]
n User qualification: trained user, see Ä Chapter 3.4 ‘User qualification’ on page 24
Continuous display ➨ ➨ or [Relays] ➨ [Relays]
Measuring channel settings
This descriptions of [Channel 1] apply correspondingly to the settings in all other measuring
channels. The procedure for entering the settings for the channel in question is identical,
however the parameters to be set may differ. Your attention is drawn to the differences,
which are also described.
Relay
A1069
Relay 1
Relay 2
6.1
Alarm relay
Limit value 1
Off
Relay timer
Off
Off
Fig. 100: Setting the [relays]
Setting [Relay 1], [Relay 2], [Alarm relay] or [Relay timer]
Only the process for setting [Relay 1] is described. The setting process for [Relay 2], the
[Relay timer] or the [Alarm relay] is the same as when setting [Relay 1].
