16.1 Setting the [mA outputs]
Continuous display ➨ ➨ or [mA outputs] ➨ [mA outputs] ➨ or [mA output 1]
[Function] Set function
mA-output 1
Function Measured value
A0985
Output range
Current on error
0 mA
20 mA
Damping
HOLD reaction
0 ... 20 mA
23 mA
-1,45 pH
15,45 pH
high
HOLD
Assignment Channel 1
Fig. 107: Setting [mA output 1]
[Function ] Adjustable value Explanation
[Function] [Off] The mA output has no function
[Measured value]
[Control variable]
[Correction value] Temperature
The mA output is held at the valid mA output value upstream of [Pause Hold] .
The following adjustable parameters are available when selecting the [Measured value] ,
[Control variable] and [Correction value] functions:
[Function ] Adjustable value Adjustable ranges or counter values
[Measured
value]
[Control
variable]
[Correction
value]
[Output range ] 0 ... 20 mA
Assignment to the required measuring range start and
end value.
4 ... 20 mA
Assignment to the required measuring range start and
end value.
Setting the [mA outputs]
