Pos. Spare parts Order number

6 SD card, industrial quality 1030506

7 SN6 socket 1036885

8 Cable threaded connector M16x1.5 1005874

9 Cable threaded connector M20x1.5 1005517

10 Counter nut, M20x1.5 1021016

The spare parts units are ordered as identity code features and replaced and configured as

described.

20.2 Replacement of Spare Parts Units

Replacement of the housing upper part with display

A2306

54321 6

Fig. 125: Replacement of spare parts units

1. Strain relief

2. Housing upper part

3. Plug, small

4. Plug, large

5. Strain relief

6. Housing lower part

Spare Parts and Accessories

180
