Parameters in the adjustable menus
Setting of the various parameters in the adjust‐
able menus
No time-controlled menu items
The controller does not exit any menu
items in a time-controlled manner, the
controller remains in a menu item until
this menu item is exited by the user.
1. Select the desired parameter in the dis‐
play using or .
ð
There is an arrow tip in front of the
selected parameter, which indi‐
cates the selected parameter.
2. Press .
ð
You are now in the setting menu for
the desired parameter.
3. You can adjust the desired value in the
setting menu using the four arrow keys
and then save it using .
ð
Range error
If you enter a value that is
outside the possible setting
range, the message
[Range error] appears after
has been pressed.
Pressing
or returns
you to the value to be set.
The controller returns to the menu
once has been pressed.
Cancelling the setting
process
Pressing
returns you to
the menu without a value
being saved.
Operating concept
12
