Tab. 16: Settable parameters of Relay 1 and Relay 2
Parameter Settable function Relay state
[Function] Set relay as:
n [Off]
n [Limit value 1]
n [Limit value 2]
n [Limit value 1 <Control variable>]
n [Limit value 2 <Control variable>]
n [Cycle]
n [Pulse length (PWM)]
Active closed (default).
Active opened.
[Assignment] Assign the relay to the relevant meas‐
uring channel:
n [Channel 1]
n [Channel 2]
n [Channel 3]
n [Channel 1+2]
n [Channel 1+2+diff]
Active closed (default).
Active opened.
Tab. 17: Settable alarm relay parameters
Parameter Settable function
[Function] Set relay as:
n [Off]
n [Alarm]
n [Limit value 1]
n [Limit value 2]
n [Limit value 1+2]
n [Pause]
Setting the [Relays]
