Configuration
Measured value channel 1
A1678
Temperature channel 1
Control variable channel 1
Measured value channel 2
Temperature channel 2
Control variable channel 2
9.1.4.1
Fig. 115: [Configuration] of the data log book
[Configuration]
of the data log book
Configuration
One file per day
A1679
Save interval
Digital inputs
Temperature channel 2
Control variable channel 2
9.1.4.13
Fig. 116: [One file per day] checked
If you uncheck
[One file per day]
, then a new
input option appears:
[File name]
.
Configuration
One file per day
A1680
Save interval
Digital inputs
Temperature channel 2
Control variable channel 2
9.1.4.13
File name
Fig. 117: [One file per day] unchecked
1. If you wish to specify a file name, then
place the cursor on
[File name]
and
press
ð
[New]
appears.
2. Place the cursor on
[New]
and press
ð
You can now enter a random name
with a maximum of 8 digits name
as well as the proposed
[DATALOG0.CSV]
and/or set from
0 to 1 ... n.
The maximum file size is 2 GB
The maximum file size is 2 GB. The SD
card needs to be the same size.
Record
A1681
New
DATALOG0.CSV
9.1.3.4.1
Fig. 118: Check the file to write it to an existing
file, here [DATALOG0.CSV]
3. If you wish to attached measured data
to an existing file, then check this file
and the data will be written to this file
If the SD card is removed, then data can be
recorded for a maximum of 24 hours in the con‐
troller's internal memory with a storage interval
of 10 seconds. Around six times as long with an
interval of 60 seconds. When the SD card is re-
inserted into the controller, then the data from
Function: Data logger
