DAC: DULCOMETER
®
, multi-parameter controller diaLog DACb
3 Package 3: 2nd measurement + control, additionally 2 pumps, addition‐
ally 3 control inputs, replaces the D2Ca
4 Package 4: pH compensation for chlorine, only based on measured vari‐
able "VA"
Software default settings
0 no default settings
1 Batch neutralisation
2 Flow neutralisation
3 pH/ORP measurement/control (pH bidirectional, ORP monodirec‐
tional)
4 pH/Cl
2
measurement/control (pH bidirectional, chlorine monodirec‐
tional)
5 pH/ClO
2
measurement/control (pH bidirectional, chlorine dioxide
monodirectional)
6 pH/Cl
2
measurement/control with disturbance variable (pH bidirec‐
tional, chlorine monodirectional)
7 ClO
2
/ORP measurement/control (CIO
2
monodirectional, ORP for
monitoring)
B BOSCH
S Presetting for swimming pool
P Presetting for private swimming pool
Connection of the measured variables
0 all sensor inputs via terminal
1 1x mV input on SN6 socket
2 2x mV inputs on SN6 socket
3 3x mV inputs on SN6 socket
Connection of digital sensors/actuators
0 none
Identity code
18
