3 2 1

I.

A1179

Fig. 12: Order number for the DAC control panel fitting kit (included with the scope of supply):

1041095.

I. Control panel

1. 1 x foam rubber caulking strip ∅3

2. Galvanised steel retaining brackets (6 off)

3. Galvanised PT cutting screws (6 off)

Punched template

Assembly and installation

36
