Read-off and operating position
–
Install the device in a favourable
position for reading and operating
(preferably at eye level).
Mounting position
–
As standard the controller is wall-
mounted.
–
Nevertheless you can fit the
controller in a control panel
using the optional fitting kit.
–
Always install the controller so
that the cable entries point down‐
wards.
–
Leave sufficient free space for the
cables.
Assembly and installation
25
