ProMinent DULCOMETER - Page 79

Measuring and control behaviour
of the controller during calibration
During calibration the actuating out‐
puts are deactivated. Exception: a
basic load or a manual control vari‐
able has been set. This remains
active. The measured value output
[standard signal output mA] is frozen,
corresponding to its settings in the
mA output menu.
When calibration/testing has been
completed successfully, all of the
error checks relating to the measured
value are restarted. The controller
saves all the determined data for zero
point and slope upon a successful
calibration.
Continuous display ➨
CAL ORP
CAL setup
A1032
Offset
21.05.2013 14:59:56
continue with <CAL>
Calibration process
Last calibration
0.0 mV
Data input offset
Fig. 48: Data input, ORP sensor calibra‐
tion (CAL)
1.
Continue with
CAL ORP
Offset
A1033
Accept with <CAL>
0.1 mV
Fig. 49: Adjusting the [Offset]
2.
Press and use the four arrow
keys to adjust the mV value of the
buffer you are using
3.
Press
4. Transfer the result of the calibration
into the controller memory by
pressing
ð
The controller operates with the
calibration results.
Calibration
79
