PRÜFTECHNIK VIBSCANNER 2 User Manual

3.2 Display and operating elements 33
3.2.1 Context line 33
3.2.2 Status bar 34
3.2.3 Display field 35
3.3 Device settings 40
3.3.1 WiFi 40
3.3.2 Date & time 41
3.3.3 Units 42
3.3.4 Sensor 43
3.3.5 Display 45
3.3.6 Route settings 45
3.3.7 Language & keyboard 47
3.3.8 Power options 47
3.3.9 About VIBSCANNER 2 48
3.4 Text editor 49
3.4.1 Basic functions 49
3.4.2 Extended functions 49
3.5 Update 51
4 - Route 53
4.1 Preparation 54
4.2 Loading the route onto the measuring device 55
4.2.1 Transferring the route via OMNITREND Center 55
4.2.2 Transferring route via file system 56
4.3 Measuring the route 58
4.3.1 Starting the route 58
4.3.2 Performing the measurement 59
4.4 Measurement tasks 62
4.4.1 Vibration measurement with rotational speed determination 62
4.4.2 Measurement on a production line 63
4.4.3 Manual input 64
4.4.4 Measurement with triaxial sensor 64
4.4.5 Temperature 65
4.5 Coded measurement locations 66
4.5.1 VIBCODE sensor for vibration measurement 66
4.5.2 VIBCODE sensor for measurement location detection 67
4.5.3 Non-contact detection or measurement locations (RFID) 67
4.5.4 Teaching in RFID transponder 68
Edition : 11.2017 4

PRÜFTECHNIK VIBSCANNER 2 Specifications

General

Brand	PRÜFTECHNIK
Model	VIBSCANNER 2
Category	Measuring Instruments
Language	English
