PRÜFTECHNIK VIBSCANNER 2 User Manual

4 - Route
This section provides information about the following topics:
4.1 Preparation 54
4.2 Loading the route onto the measuring device 55
4.2.1 Transferring the route via OMNITREND Center 55
4.2.2 Transferring route via file system 56
4.3 Measuring the route 58
4.3.1 Starting the route 58
4.3.2 Performing the measurement 59
4.4 Measurement tasks 62
4.4.1 Vibration measurement with rotational speed determination 62
4.4.2 Measurement on a production line 63
4.4.3 Manual input 64
4.4.4 Measurement with triaxial sensor 64
4.4.5 Temperature 65
4.5 Coded measurement locations 66
4.5.1 VIBCODE sensor for vibration measurement 66
4.5.2 VIBCODE sensor for measurement location detection 67
4.5.3 Non-contact detection or measurement locations (RFID) 67
4.5.4 Teaching in RFID transponder 68
4.6 RPM measurement using the stroboscope 70
4.6.1 Verifying/measuring rotational speed 70
4.7 Route options 73
4.7.1 Remeasuring 73
4.7.2 Moving measurement into history 73
4.7.3 Deleting a measurement 74
4.7.4 Deleting route from the measuring device 75
4.7.5 Skipping a measurement 75
4.7.6 Documenting the event 76
4.8 Route status 78
4.8.1 Measurement status 78
4.9 Transferring measurement data for analysis 79
4.9.1 Transferring measurement data via direct connection 79
4.9.2 Transferring measurement data via the file system 80
VIBSCANNER 2│Operating Instructions 53

PRÜFTECHNIK VIBSCANNER 2 Specifications

General

Brand	PRÜFTECHNIK
Model	VIBSCANNER 2
Category	Measuring Instruments
Language	English
