ULTRA 4
INSTRUCTI
ON MANUAL
108
OCM: Available when U
ltra Wizard =
Flow
P730
Head
Breakpoint 1
P731
Flow
Breakpoint 1
P732
-
P791
Head & Flow
Breakpoints
2 to 31
P792
Head
Breakpoint 32
P793
Flow
Breakpoint 32
PMD
Setup
P700
PMD Type
P701
Primary
Measuring
Device
P702
Calculation
P703
Minimum
Head
P704
Maximum
Head
P705
Maximum
Flow
P706
Volume
Units
P707
Time Units
P708
Flow
Decimal
P709
Flow Cutoff
Dimensions
P710
Dimension ‘A’
P711
Dimension ‘B’
P712
Dimension ‘C’
P713
Dimension ‘D’
P714
Roughness
Coefficient
P715
Water
Temperature
P717
Exponent
Value
P718
K Factor
P719
Parshall Throat
Width
Calcs
P720
Calc. 1
P721
Calc. 1
P722
Calc. 2
P723
Calc. 3
P724
Calc. 4
P725
Calc. 5
Breakpoints
Tables
P796
Reset
B’points
P797
Number
of
B’points
Set
Average
Flow
P863
Average
Flow
P864
Average
Time
107
109
