PULSAR MEASUREMENT
53
Quick Setup
Xducer (P101)
0 = None
1 = dB3
2 = dB6 (default)
3 = dB10
4 = dB15
5 = dB25
6 = dB40
7 = dBS6
8 = dBMach3
9 = dBR16
10 = dBR8
Material (P102)
1 = Liquid
2 = Solid
3 = Closed Tank
Measurement
units (P104)
1 = metres (default)
2 = Centimetres
3 = Millimetres
4 = Feet
5 = Inches
Empty Level
(P105)
Span (P106)
No. of Controls
0 = 0 Control
1 = 1 Control
2 = 2 Controls
3 = 3 Controls
4 = 4 Controls
0 = No Control
1 = Control
Down
2 = Control Up
Quick Setup
1 = Level
2 = Volume
For each
Control Relay
1 = Set to Relay 1
2 = Set to Relay 2
3 = Set to Relay 3
4 = Set to Relay 4
Alarm No. *
1 = Set to Relay 1
2 = Set to Relay 2
3 = Set to Relay 3
4 = Set to Relay 4
Alarm ID (P2*2)
1 = High
2 = Low
3 = Hi-Hi
4 = Lo-Lo
5 = Loss of Echo
No. of Alarms
0 = 0 Alarms
1 = 1 Alarm
2 = 2 Alarms
3 = 3 Alarms
4 = 4 Alarms
