Pulsar Ultra 4 User Manual

PULSAR MEASUREMENT
13
Product Specification
PHYSICAL
Wall Mount outside Dimensions
150 x 130 x 64mm (5.9 x 5.1 x 2.5”)
Weight
Nominal 700g
Enclosure Material/Description
Polycarbonate flame resistant to UL94-5V
Cable entry detail
3 x M20 cable glands, for cable dia. 5 to 13mm (0.2” to
0.5”)
Fascia Mount outside
dimensions
160 x 180 x 64mm (6.3 x 7.1 x 2.5”)
Weight
1.3kg
Enclosure material/description
Polycarbonate flame resistant to UL94-5V
Transducer Cable Extensions
2-core screened (minimum)
Maximum Separation
1000m (3,280 ft), 500m (1,640 ft) for mmWave
ENVIRONMENTAL
IP Rating (Wall)
IP67 / NEMA 4X
IP Rating (Fascia)
IP64
Max. & min. temperature
(electronics)
-20°C to +45°C (-4°F to +113°F)
Flammable atmosphere approval
Safe area: compatible with approved transducers and
sensors. (see spec. sheets)
CE Approval
See EU Declaration of Conformity
UL Approval
UL61010-1
PERFORMANCE
Accuracy
0.25% of the measured range or 6 mm (whichever is
greater). ± 2mm for mmWAVE RADAR
Resolution
0.1% of the measured range or 2 mm (whichever is
greater)
Max. Range
Dependant on transducer (maximum 40m dB40)
Min. Range
Dependent upon application and transducer
(minimum zero dB Mach3)
Rate Response
Fully adjustable
ECHO PROCESSING
Description
DATEM (Digital Adaptive Tracking of Echo Movement)
Technology
Ultrasonic and MCW Radar
