PULSAR MEASUREMENT
165
mA Failsafe
P840 mA Failsafe Mode
This parameter determines what happens to the mA output in the event of
the unit going into fail-safe mode. The default is to do the same as the
system fail-safe (P808), but this can be overridden to force the mA output
to an independent fail-safe mode as follows:
mA output will fail as per P808
mA output will retain its last known value.
mA output will fail to its low condition.
mA output will fail to its high condition.
Compensation Parameters
Offset
P851 Measurement Offset
The value of this parameter is added to the measured distance, in
Measurement Units (P104), and will affect everything including the reading
on the display, the relay setpoints and the mA output.
Temperature
P852 Temperature Source
This parameter determines the source of the temperature measurement. By
default, it is set to automatic (P852=1), which will automatically detect if a
temperature sensor is available from the transducer. If for any reason, no
temperature input is received, then the Fixed Temp value is used, as set by
P854.
The temperature source can be specifically set as follows:
Will automatically select transducer temperature
sensor, if available, or fixed temperature (P854) if
no temperature sensor found.
Always uses temperature reading from transducer.
Always uses fixed temperature (P854)
