Pulsar Ultra 4 - Dimensions

PULSAR MEASUREMENT
117
OPTION
DESCRIPTION
When Ultra Wizard = Level/Volume
5 = dB25
Transducer is a dB25. Range 0.6 to 25m (1.96 to 82.02 ft)
2 = dB6
Transducer is a dB40. Range 1.2 to 40m (3.93 to 131.23 ft)
Available for all Ultra Wizard options
*9 = dBR16
Transducer is a dBR16. Range 0.077 to 16m (0.25 to 52.49ft)
*10 = dBR8
Transducer is a dBR8. Range 0.077 to 8m (0.25 to 26.25 ft)
*The signal emanates from the curved face of the radar, but for the purposes
of measurement it is taken from the drip shield.
P102 Material
This parameter should be set to the type of material being monitored.
OPTION
DESCRIPTION
1 = Liquid (Default)
Used for liquids and flat solid materials.
2 = Solid
Used for sold material that is heaped or at an angle.
3 = Closed Tank
Use for applications within a closed tank or where a
secondary echo response may become focused to
create a larger echo than the first.
Dimensions
P104 Measurement Units
This parameter sets the units you want to use for programming and display.
OPTION
DESCRIPTION
1 = metres (Default)
All units of measurement are Metres
2 = cm
All units of measurement are Centimetres
3 = mm
All units of measurement are Millimetres
4 = feet
All units of measurement are Feet
5 = inches
All units of measurement are Inches
