Pulsar Ultra 4 - Profibus

ULTRA 4 INSTRUCTION MANUAL
180
Profibus
Terminal connections, colours of cables only used for example purposes:
P130 Device Mode
This parameter is used to determine whether the Ultra 4 is a Slave device or
not.
OPTION
DESCRIPTION
0 = Off (Default)
Communication is switched OFF
1 = Slave
Ultra 4 is set as a Slave unit
P132 Device Address
This is the Profibus slave address of the Ultra 4. Default = 126
P143 Address Locked
This parameter determines whether the unit address is locked and unable to
be changed by the Profibus master.
0 = No (Default) and 1 = Yes.
RS485 + Cable
RS485 - Cable
