To program the unit for Example 3 using the Quick Setup menu, proceed
as follows. If required access Program Mode, by keying in the passcode
1997 and press ENTER. Using the ‘right’ arrow key, go to the Quick Setup
menu and press ENTER. And as prompted, by the questions, select the
relevant option and press ENTER.
This example is for a cylindrical flat-bottomed vessel. See P600 Vessel
Shape in the following Parameter Guide, for a description of all the other
vessel shapes you could select, and dimensions required. Programming is
now complete, and the unit can be returned to the run mode. To do this,
press CANCEL until Run Mode? is displayed on the screen. Press ENTER,
and the Ultra 4 will now return to Run Mode
QUESTION
OPTION
Level/Volume
1 = Level App.
Control
1 = Control down
No. of controls
1 = 1 Relay
Control no.1
1 = Set to relay 1
No. of alarms
2 = 2 Alarms
Type alarm 1
1 = High
Alarm no.1
1 = Set to relay 2
Type alarm 2
2 = Low
Alarm no.2
The unit knows that only Relay 3 is
available and so will automatically set
Alarm 2 to Relay 3.
Xducer (P101)
2 = dB6
Material (P102)
1 = Liquid
Measurement units (P104)
1 = Metres
Empty Level (P105)
3.5m
Span (P106)
2.8m
Vessel shape (P600)
0 = Cylindrical flat base
Vessel dimensions
Enter vessel dimensions as requested
(depends on vessel shape chosen)
Volume units
Select as required
Max Volume (Read only)
Displays the Max volume as calculated
by the Ultra 4. This is a read only
parameter.
