Table 4-3: Test Patterns
Pattern Name
Variant
Options
Range of Values
Pixel values in RGB, 10bit
with limited range (TV)
mode.
Outer background:
R=64 G=64 B=64
Outer blinking box:
R=80/64 G=80/64 B=80/64
Inner blinking box:
R=36/64 G=36/64 B=36/64
Top most stair value:
R=940 G=940 B=940
Second stair value:
R=720 G=720 B=720
Third stair value:
R=560 G=560 B=560
Fourth stair value:
R=448 G=448 B=448
Bottom stair value:
R=360 G=360 B=360
Pixel values in RGB, 12bit
with limited range (TV)
mode.
Outer background:
R=256 G=256 B=256
Outer blinking box:
R=320/256 G=320/256 B=320/256
Inner blinking box:
R=144/256 G=144/256 B=144/256
Top most stair value:
R=3760 G=3760 B=3760
Second stair value:
R=2880 G=2880 B=2880
Third stair value:
R=2240 G=2240 B=2240
Fourth stair value:
R=1792 G=1792 B=1792
Bottom stair value:
R=1440 G=1440 B=1440
White Pluge Pattern
Application: To set the contrast
and brightness controls on
fixed pixel displays.
No Variants
Pixel values in RGB, 8bit
with limited range (TV)
mode.
Top background:
R=16 G=16 B=16
Top dark vertical line:
R=8 G=8 B=8
Top larger (outer) box:
R=18 G=18 B=18
Top smaller (inner) box:
R=20 G=20 B=20
Bottom background:
R=235 G=235 B=235
Bottom larger (outer) box:
R=232 G=232 B=232
Bottom smaller (inner) box:
R=230 G=230 B=230
