882 Video Test Instrument User Guide (Rev A.35) 211
DVI/HDMI Signal Analyzer
Command Description
TMAU Launch signal timing analysis measurement
TMAX:RPTG Enable/disable HTML report of signal timing analysis measurement
results
TMAX:SCAN Get signal timing analysis measurement value
PNSA Set how often pseudo-random noise pixels are calculated
PNSM Set pseudo-random noise seed and run-length values
PNSG Enable/disable pseudo-random noise output
PNSP Set pseudo-random noise sequence type
PNGU Update generator with pseudo-random noise generator test
PNAU Update generator with pseudo-random noise generator test and
measure all required parameters
GCET? Get number of RGB and total pixels errors
GFED? Get details on first error encountered
GNPT? Get number of measured pixels after pseudo noise measurement
GPER? Get pixel error rate after pseudo noise measurement
HPDG Set assertion pulse width of analyzer’s hot plug pulse
PDAX:FRMS Set number of frames to analyze in pixel data analysis test
PDAX:FRMS Save a captured reference frame to a file to a file on the PCM card
PDAX:CAPF Capture a reference frame for pixel data analysis test
PDAX:GFCL Load a captured reference frame from a file on the PCM card
PDAX:GFCU Apply the loading of a captured data file
PDAX:MXER Set maximum number of detailed errors to record in pixel data
analysis test
PDAX:RPTG Enable/disable HTML report of pixel data analysis test results
PDAX:REFG Enable/disable automatic reference frame capturing
PDAX:ERRQ Get one or more recorded detailed error records
PDAX:NERR Get number of errors during a pixel data analysis test
PDAX:PASS Enble or disable video pass through
PDAU Run pixel data analysis test
GPEL? Get pixel color components
