48 Chapter 2 Testing Video Displays
Note: The list of images that appears when you press the Content key may be a
filtered or abbreviated list. You may have disabled certain image catalogs, preventing
the images in those catalogs from appearing on the Content list. For more information
about image catalogs, see “Creating image catalogs” on page 229.
3. Choose an image by pressing the adjacent soft key.
The table below provides a summary of display characteristics and the images used to
evaluate them. For details on the images and display attributes, see Appendix B, “Image
Reference.”
Display type Display test Recommended images
Analog CRT Geometry
(pin and barrel, linearity)
Static images
Hatch (TVHatch, Hatch_16, Hatch_20), Cir-
clesL, Geom_1 - Geom_5, SMPTE133
Focus Focus_@6, Focus_@7, Focus_@8,
Focus_@9, Text_9, Text_9T, Text_11,
Text_12T, Text_16
Photometry (chrominance,
contrast, levels)
Flat, Flat07, Flat13, Flat20, Flat27, Flat33,
Flat40, Flat47, Flat53, Flat60, Flat67, Flat73,
Flat80, Flat87, Flat93, FlatGray, Flat_01,
Flat_02, Flat_03, Flat_04, Flat_05, Flat_06,
Flat_07, Flat_08, Flat_09, Flat_10, Flat_11,
Flat_12, Flat_13, Flat_14, Flat_15, Flat_16,
Ramp_B, Ramp_G, and Ramp_R,
ColorBar, SMPTEbar, TVBar100 & TVBar_75
(TV formats only)
Luminance SMPTE133 (grayscale), Grays5, Grays9,
Grays11, Grays16, Grays32, Grays64
Gamma correction SMPTE133 (checkerbox)
Resolution BurstTCE, Burst (TV formats only), Grill_11,
Grill_15, Grill_22, Grill_33, Grill_44
Pulse (CE SDTV) PulseBar
Centering Outline0, Outline1, Outline2, Outline3
Voltage Regulation
Regulate
Electromagnetic
Interference
EMITest1, EMITest2, EMITest3, EMITest4,
EMITest5
