October, 1996 6880902Z36-B 6-17
GM300 Radio Service Software Manual Accessory Connector (16 Channel Models Only)
Customizing the Expanded Accessory Connector
6
Remote
RSS LOCATION
DEFINITION This package is designed for applications where the radio will be remotely con-
trolled. This might be an extended local deskset, DC remote deskset, tone remote
deskset, or a second microphone.
DEFAULT/CHOICES Refer to Table 10-19 on page 10-13 in Appendix H for defaults.
SEE ALSO External Accessories, Internal Accessories, DTMF Decoder Board
PROGRAMMING PROCEDURE
1. Press F4 at the MAIN MENU to get to the
CHANGE/VIEW CODEPLUG MENU.
4. Use the ↑ ↓ arrow keys to select Remote.
2. At the CHANGE/VIEW CODEPLUG MENU,
press F2 to get to the RADIO-WIDE screen.
5. To customize the accessory package, press F9 to
get to the ACCESSORY CONNECTOR CON-
FIGURATION screen and make the desired
changes.
3. Press Tab or Enter/Return until the Acc. Exter-
nal field is highlighted.
MAIN
MENU
➠
F4
➠
F2
CHANGE/
VIEW
➠
Tab
RADIO
WIDE
Acc. External
field
To Next Page
