Accessory Connector (16 Channel Models Only) GM300 Radio Service Software Manual
6-18 6880902Z36-B October, 1996
Customizing the Expanded Accessory Connector
6
RPB50 Interface
RSS LOCATION
DEFINITION This paging-based interface is designed for the RPB50.
DEFAULT/CHOICES Refer to Table 10-25 on page 10-15 in Appendix H for defaults.
IMPORTANT NOTE Incompatible with DTMF Decoder Board.
SEE ALSO External Accessories, Internal Accessories, DTMF Decoder Board
PROGRAMMING PROCEDURE
1. Press F4 at the MAIN MENU to get to the
CHANGE/VIEW CODEPLUG MENU.
4. To customize the accessory package, press F9 to
get to the ACCESSORY CONNECTOR CON-
FIGURATION screen and make the desired
changes.
2. At the CHANGE/VIEW CODEPLUG MENU,
press F2 to get to the RADIO-WIDE screen.
3. Press Tab or Enter/Return until the Acc. External
field is highlighted.
MAIN
MENU
➠
F4
➠
F2
CHANGE/
VIEW
➠
Tab
RADIO
WIDE
Acc. External
field
To Next Page
