Getting Started GM300 Radio Service Software Manual
2-2
6880902Z36-B October, 1996
Assembling The Hardware
2
1.
Computer
.
Recommend IBM-XT/AT or compatible, IBM con-
vertible or IBM System/2 Model 30/50/70, with
640 K of RAM, and one diskette drive plus one hard
disk drive. Computer should run DOS 5.0. or
greater. See Hardware Platform - below.
2.
Cable
.
Radius
HKN9216
. Radio Interface Box (RIB)-to-
IBM-AT cable. Has a 9-pin end and a 15-pin end.
3.
RIB
.
Radius
HLN9214
. Radio Interface Box.
4.
RIB Power Supply
.
Radius
HSN9412
.
(110 VAC) Using the power supply is more reliable
than using a weak battery. A 220 VAC wall supply
is available (01-80358A56).
(For laptop computer and on-the-road use only,
omit the RIB Power Supply and use 9V battery (not
included)).
Warning: LED remains lit with a weak battery - this
may cause certain errors on screen. Use a fresh 9V bat-
tery.
5.
Cable
.
Radius
HKN9217
. RIB-to-Radio cable.
6.
Radio
.
Radius GM300 Mobile Radio.
