R&S FPC Series - Sweep Configuration

Analog Demodulation
R&S
®
FPC
155User Manual 1178.4130.02 ─ 07
Table 16-5: Minimum and maximum modulating frequencies for audio lowpass: DBW/30
Demodulation bandwidth Modulating frequency [Hz]
Minimum Maximum
2000000 185 30303
989000 90 15152
650000 70 9848
500000 45 7576
300000 30 4545
200000 20 3030
100000 10 1515
50000 5 758
30000 3 455
20000 3 303
10000 3 152
Table 16-6: Minimum and maximum modulating frequencies for audio lowpass: DBW/100
Demodulation bandwidth Modulating frequency [Hz]
Minimum Maximum
2000000 60 10000
989000 30 5000
650000 25 3250
500000 15 2500
300000 10 1500
200000 6 1000
100000 3 500
50000 3 250
30000 3 150
20000 3 100
10000 3 50
16.5 Sweep Configuration
Access: "Sweep"
Remote commands to control the measurement:
●
Chapter 19.14.5, "Sweep Control", on page 311
Sweep Configuration
