R&S FPC Series User Manual

Remote Control
R&S
®
FPC
314User Manual 1178.4130.02 ─ 07
Suffix:
<n>
.
irrelevant
Parameters:
<ResultDisplay> 'XTIM:DDEM:ERR:MPH'
Selects the modulation error result display.
'XTIM:DDEM:EYE'
Selects the eye diagram.
'XTIM:DDEM:MEAS'
Selects the modulation depth (ASK) or modulation deviation
(FSK) result display.
'XTIM:DDEM:SYMB'
Selects the symbol stream result display.
*RST: 'XTIM:DDEM:MEAS'
Example: //Select eye diagram
CALC:FEED 'XTIM:DDEM:EYE'
Manual operation: See "Eye Diagram" on page 392
See "Symbols" on page 392
See "Modulation Depth / Modulation Deviation" on page 392
See "Modulation Error" on page 392
CALCulate<n>:MARKer:FUNCtion:DDEMod:CARRier[:RESult]?
This command queries the carrier power of the measured signal.
Suffix:
<n>
.
irrelevant
Return values:
<Power> <numeric value>
Default unit: dBm
Example: //Query carrier power
CALC:MARK:FUNC:DDEM:CARR?
Usage: Query only
CALCulate<n>:MARKer:FUNCtion:DDEMod:CFDRift[:RESult]?
This command queries the carrier frequency drift of the measured signal.
Prerequisites for this command
●
Select FSK demodulation ([SENSe:]DDEMod).
Suffix:
<n>
.
irrelevant
Return values:
<Frequency> <numeric value>
Default unit: Hz/symbol
Remote Commands of the Digital Demodulation
