Remote Control
R&S
®
FPC
228User Manual 1178.4130.02 ─ 07
Prerequisites for this command
Turn on signal source (SOURce:TG[:STATe]).
Parameters:
<Level> <numeric level>
*RST: 0
Default unit: dBm
Example: //Define signal source output power
SOUR:TG ON
SOUR:TG:POW -10DBM
Manual operation: See "Level" on page 367
SOURce:TG[:STATe] <State>
This command turns the signal source on and off.
Parameters:
<State> ON | OFF | 1 | 0
Configure the frequency characteristics of the output signal with
one of the following commands.
CW signal: SOURce:TG:FREQuency:AUTO
Tracking generator: SOURce:TG:AUTO
Configure the output level with SOURce:TG:POWer.
*RST: OFF
Example: //Turn on signal source
SOUR:TG ON
Manual operation: See "Off" on page 367
19.10 Calibration
CALibration<n>:ABORt...................................................................................................228
CALibration<n>:CONTinue?............................................................................................229
CALibration<n>:MODE?................................................................................................. 229
CALibration<n>:STARt?..................................................................................................230
CALibration<n>:STATus?................................................................................................231
SYSTem:PRESet:CALibration:DISCard............................................................................ 231
CALibration<n>:ABORt
This command aborts calibration.
Suffix:
<n>
.
irrelevant
