Prerequisites for this command
●
Turn on signal source (SOURce:TG[:STATe]).
●
Turn off tracking generator (SOURce:TG:AUTO).
●
Select fixed frequency mode (SOURce:TG:FREQuency:AUTO).
Parameters:
<Frequency> <numeric value>
Default unit: Hz
Example: //Define fix frequency of generated signal
SOUR:TG ON
SOUR:TG:FREQ:AUTO OFF
SOUR:TG:FREQ 100MHZ
Manual operation: See "CW" on page 367
SOURce:TG:FREQuency:AUTO <State>
This command couples and decouples the output frequency of the signal source to the
center frequency.
Prerequisites for this command
●
Turn on signal source (SOURce:TG[:STATe]).
●
Turn off tracking generator (SOURce:TG:AUTO).
Parameters:
<State> ON | 1
Generates a signal whose frequency corresponds to the center
frequency (signal source mode "Coupled CW").
You can define the center frequency with [SENSe:
]FREQuency:CENTer.
OFF | 0
Generates a signal whose frequency remains the same (signal
source mode "CW").
You can define the fix output frequency with SOURce:TG:
FREQuency.
Example: //Couple signal source frequency to center frequency
SOUR:TG ON
SOUR:TG:FREQ:AUTO ON
//Define center and output frequency
FREQ:CENT 100MHZ
Manual operation: See "Coupled CW" on page 367
SOURce:TG:POWer <Level>
This command defines signal source output power.
Signal Source Configuartion
