TRACe[:DATA]?
This command queries the trace data (measurement results in graphical result dis-
plays).
Return values:
<Results> Returns one value for each measurement point.
The type of value depends on the measurement and result dis-
play.
"Symbols": returns the symbol stream.
"Modulation Deviation": returns one value (frequency deviation)
for each symbol in Hz.
"Modulation Depth": returns one value (modulation depth) for
each symbol in PCT.
"Modulation Error": returns one value for each symbol. The unit
is either Hz (FSK) or PCT (ASK).
Example: //Query results
TRAC?
Usage: Query only
19.15.2 Measurement Configuration
[SENSe:]DDEMod:BURSt[:STATe]................................................................................... 318
[SENSe:]DDEMod:FILTer:ALPHa.....................................................................................318
[SENSe:]DDEMod:FILTer:NAME......................................................................................319
[SENSe:]DDEMod:FILTer[:STATe].................................................................................... 319
[SENSe:]DDEMod:SRATe............................................................................................... 320
[SENSe:]DDEMod:TIME................................................................................................. 320
[SENSe:]DDEMod:BURSt[:STATe] <State>
This command turns burst processing on and off.
Parameters:
<State> ON | OFF | 1 | 0
*RST: OFF
Example: //Turn on burst processing
DDEM:BURS ON
Manual operation: See "Demod Parameters" on page 391
[SENSe:]DDEMod:FILTer:ALPHa <Alpha>
This command defines the roll-off factor of the measurement filter (alpha or BT value).
Remote Commands of the Digital Demodulation
