R&S FPC Series User Manual

Remote Control
R&S
®
FPC
325User Manual 1178.4130.02 ─ 07
Parameters:
<Format> LOSS
Selects the cable loss format.
Available for cable loss measurements.
MAGNitude
Selects the return loss format.
Available for reflection and DTF measurements.
PHASe
Select the phase format.
Available for reflection measurements.
SMITh
Select the Smith chart format.
Available for reflection measurements.
VSWR
Selects the SWR format.
Available for reflection and DTF measurements.
Example:
//Select measurement format
MEAS:MODE REFL
MEAS:FORM VSWR
Manual operation: See "Format" on page 396
19.16.1.2 DTF Configuration
CALCulate<n>:DTF:CABLe:PRESet................................................................................ 325
CALCulate<n>:DTF:DISTance:STARt...............................................................................326
CALCulate<n>:DTF:DISTance:STOP............................................................................... 326
CALCulate<n>:TRANsform:DTFault:PEAK:COUNt?.......................................................... 326
CALCulate<n>:TRANsform:DTFault:PEAK:DATA<peak>?..................................................327
CALCulate<n>:TRANsform:DTFault:PEAK[:STATe]........................................................... 327
CALCulate<n>:TRANsform:DTFault:PEAK:THReshold...................................................... 328
CALCulate<n>:DTF:CABLe:PRESet <CableModel>
This command selects a cable model.
Prerequisites for this command
●
Select the DTF measurement (MEASurement<n>:MODE).
Suffix:
<n>
.
irrelevant
Parameters:
<CableModel> String containing the file name of the cable model.
Example: //Select cable model
MEAS:MODE DTF
CALC:DTF:CAB:PRES '5088-HLFR.CBLMOD'
Manual operation: See "Select Cable Model" on page 397
See "Clear Cable Model" on page 397
Remote Commands of the VNA Application
