Remote control basics
R&S
®
NRPxxP
138
User Manual 1
179.5760.02 ─ 02
0
1
2
3
4
5
6
7
8
9
10
1
1
12
13
14
15
0
Sensor initializing
0
0
0
0
0
0
0
0
0
0
0
0
0
0
+
Figure 10-1
1: Operation sense status register
Querying the register:
●
STATus:OPERation:SENSe:CONDition?
●
STATus:OPERation:SENSe[:SUMMary][:EVENt]?
T
able 10-13: Used operation sense status bits and their meaning
Bit no.
Short description
Bit is set if
1
Sensor initializing
Power sensor is being initialized.
Status reporting system
137
139
