R&S NRP P Series User Manual

Remote control basics
R&S
®
NRPxxP
137User Manual 1179.5760.02 ─ 02
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
0
Sensor waiting for trigger
0
0
0
0
0
0
0
0
0
0
0
0
0
0
+
Figure 10-10: Operation trigger status register
Querying the register:
●
STATus:OPERation:TRIGger:CONDition?
●
STATus:OPERation:TRIGger[:SUMMary][:EVENt]?
Table 10-12: Used operation trigger status bits and their meaning
Bit no. Short description Bit is set if
1 Sensor waiting for trigger Power sensor is waiting for a trigger event. When the trigger
event occurs, the power sensor changes into the measuring
state.
10.2.5.4 Operation sense status register
The CONDition register contains information whether a power sensor is being initial-
ized. The EVENt register contains information whether an initialization was started or
completed since the last query.
A power sensor is initialized if:
●
Supply voltage is switched on (power-up).
●
Power sensor was connected.
●
Reset was performed using:
– *RST
– SYSTem:PRESet
