7. Appendix Technical Data - REA ScanCheck 3n
Charger voltage supply via supplied power-over-Ethernet
Input: DC 48 V / 0.5 A operation, 0.32 A max. charge
current
Battery operation 4 x 1.2 V / 2,500 mAH NiMH batteries, rechargeable
Housing Aluminum, powder-coated, black
Keyboard 21 short-stroke keys
Display Color TFT graphic display, 320 x 240 pixels, 16bit
Laser diode Protection class 2, wavelength 670nm, <1mW at 5 MHz
Laser safety In accordance with DIN EN 60825; 1993
Laser aperture Selectable aperture 6, 8, 10 mil, optional 20 mil
Scan speed Approx. 400 scans/sec., one of 10 mirrors is used, approx.
1 measurement/sec.
Processor ARM 9®, 32Bit 180 MHz
Memory Flash-ROM 16 MB,
1 GB RAM with internally inserted MMC card,
Operating system ElinOS, Embedded Linux Operating System
Optional software expansions with Comparator function, Article Database 32, TransWin32 for
transferring the codes to a PC and for remote control
Code types EAN-13, UPC-A, UPC-E with/without ADD-ON, EAN-8, 2/5
Interleaved with/without verification character, ITF-14,
postal freight, Code 39 with/without verification character,
PZN, Code 32, Code 128, GS1-128 with/without content
verification, GS1-DataBar
Code types, optional 2/5 3 Bars, 2/5 5 Bars, 2/5 IATA, 2/5 Baggage, 2/5 DHL
Express (postal freight code), Code39 Full ASCII, Code93,
MSI, Plessey, Code128UPU, Code39UPU, Code39HIBC,
Code128HIBC, Codabar Monarch (18), LAETUS
Pharmacode, LAETUS MiniPharmaCode
Interfaces Printer activation via USB host port, Type A
PoE power supply/charger connection and Ethernet data
communication via RJ-45 Ethernet port,
