7.1 Appendix Technical Data - PoE Power Supply / Charger for REA ScanCheck 3n
Input voltage 100 –240 Volt AC / 50 – 60 Hz, 0.32 A ~
Connection via 3-pole cold unit plug socket and network
connection line with grounding plug.
Output voltage 48 V / 0.32 A, DC, electronically regulated, short-circuit
proof
PIN 4, 5 +48V, PIN 7, 8 Return .
Connection to ScanCheck 3n via
Power-over-Ethernet, RJ 45 port "OUT"
Network connection via RJ 45 port "IN"
Housing ABS plastic, anthracite
Temperature Operation 0 °C - +65 °C
Storage -20 °C - +65 °C,
Humidity Relative, max. 80%, non-condensing
Dimensions 140 mm x 65 mm x 38 mm (W x D x H)
Weight 300 g
Maintenance Zero-maintenance
Socket primary adapter Available for: Euro, US, UK socket, others upon request
Secondary connection via supplied Ethernet cable, Cat5, with RJ 45
plugs, length approx. 3m each.
