2. The Delivery Components of the REA ScanCheck 3n
In the standard version, the REA ScanCheck 3n is supplied in the following configuration and always in
a specialized transport box with form insert.
A REA ScanCheck 3n consists of the following components
(Network PoE version from May 2009):
• Bar code verification unit REA ScanCheck 3n
• Calibration card for white balance and code size calibration incl. protocol of a reference
measurement for verification tool monitoring
• Operating manual (this document)
• Transport box with special fitted foam, optional transport case
• Four rechargeable Mignon NiMH AA batteries (already installed in the REA ScanCheck 3's
battery compartment)
• 1 PoE power supply (100 - 240 volts~; 0.4A; 50-60Hz~) with cold unit socket according to
IEC-60320 C5 / C6
• Power connection cable with cold unit plug and power plug for the standard ordered (Euro, UK,
USA)
• 2 network cables, highly flexible, RJ45 CAT5, approx. 2 m long
• 1 cross-over adapter for using a network cable with rotated connections
• 1 CD-ROM with all REA Verifier documents and program files
A REA ScanCheck 3 consists of the following components (USB version up to May 2009):
• Bar code verification unit REA ScanCheck 3
• Calibration card for white balance and code size calibration incl. protocol of a reference
measurement for verification tool monitoring
• Operating manual (this document)
• Transport box with special fitted foam, alternatively transport case
• Four rechargeable Mignon NiMH AA batteries (already installed in the REA ScanCheck 3's
battery compartment)
• Universal plug power supply (100 - 240V), secondary 9V, with connection cable with low
voltage hollow plug socket
• Primary plug adapter (EURO, UK or US according to delivery country, already installed)
• Connection cable for data interface and charge unit (cable with CompShield plug, hollow plug
and USB plug, type A)
