RFL 9660 RFL Electronics Inc.
April 24, 2007 14-23 (973) 334-3100
Table 14-6. Replaceable parts, dc-input power supply modules for RFL 9660 Digital Switch - continued.
Circuit Symbol
(Figs. 14-11 thru 14-13)
Description
Part Number
R48
R50
R54
R56,64
R61,69
R70
RT1
CR1
CR2,3
CR4
CR5
CR6
CR7
CR8
CR9
CR10,14,19,23
CR11,13,16,18,20,22
CR12,17,21
CR15
DS1-3
Q1,2
RESISTORS - continued.
Resistor,wirewound,0.25Ω,10%,3W,Clarostat Type VC3D or equiv.
Resistor,metal film,22.1KΩ,1%,1/4W, Type RN1/4
Resistor,metal film,280Ω,1%,1/4W, Type RN1/4
Resistor,metal film,12.7KΩ,1%,1/4W, Type RN1/4
Resistor,metal film,169KΩ,1%,1/4W, Type RN1/4
Resistor,zero-ohm,1/4-watt size,Corning OMA07 or equiv.
Thermistor,25K @ 25deg C,10%,Keystone RL 1007-13.8-120-D1 or equiv.
SEMICONDUCTORS
Transient voltage suppressor,breakdown voltage dependent upon model:
RFL 9125B 24DCPS: 31.4- to 34.7-volt breakdown,
General Semiconductor 1.5KE33A or equiv.
RFL 9125B 48DCPS: 64.6- to 71.4-volt breakdown,
General Semiconductor 1.5KE68A or equiv.
RFL 9125B 125DCPS: 190- to 210-volt breakdown,
General Semiconductor 1.5KE200A or equiv.
Diode,Schottky,1A,30V,1N5818
Rectifier,comon-cathode,type dependent upon model:
RFL 9125B 125DCPS: 2-diode,500V,16A,50-ns TRR,
3-terminal TO-220 case, General Instrument FEP16HT or equiv.
All Others: Same as CR7.
Transient voltage suppressor,breakdown voltage dependent upon model:
RFL 9125B 24DCPS: 66.7V,4.7A,500W for 1 ms,Motorola SA60 or equiv.
RFL 9125B 48DCPS: 133V,2.3A,500W for 1 ms,Motorola SA120 or equiv.
RFL 9125B 125DCPS: 189V,1.6A,500W for 1 ms,Motorola SA170 or equiv.
Rectifier,common-anode,2-diode,200V,16A,35-ns TRR,
3-terminal TO-220 case,General Instrument FEN16DT or equiv.
Rectifier,common-cathode,2-diode,200V,16A,35-ns TRR,
3-terminal TO-220 case,General Instrument FEP16DT or equiv.
Diode,Zener,15V,5%,1.5W,1N5929A
Diode,Zener,5.1V,5%,400mW,1N751A
Diode,silicon,100V,3A,1N5401
Diode,silicon,1N914B or 1N4448
Diode,Schottky high-current barrier,5A,60V,DO-201AD package,
General Instrument SB560 or equiv.
Diode,Zener,7.5V,5%,1W,DO-41 case,1N4737A
Light-emitting diode,green,right-angle PC mount,Industrial Devices 5300H5 or equiv.
Transistor,type dependent upon model:
RFL 9125B 24DCPS: N-channel MOSFET,100V,27A,
TO-220AB plastic case,International Rectifier IRF540 or equiv.
RFL 9125B 48DCPS: N-channel FET,200V,18A,TO-220AB plastic case,
International Rectifier IRF640 or equiv.
RFL 9125B 125DCPS: N-channel FET,400V,10A,TO-220AB plastic case,
International Rectifier IRF740 or equiv.
1100 806
0410 1417
0410 1235
0410 1394
0410 1502
1510 2217
30058
30447
30448
30449
30073
30460
30078
30079
30083
30489
30490
30053
37497
94287
26482
100513
34410
32567
0715 26
0716 27
0715 28
