RFL 9660 RFL Electronics Inc.
April 24, 2007 14-24 (973) 334-3100
Table 14-6. Replaceable parts, dc-input power supply modules for RFL 9660 Digital Switch - continued.
Circuit Symbol
(Figs. 14-11 thru 14-13)
Description Part Number
Q3,5-8
Q4
U1
U2
U3
U4,5
U6
F1
L1,2
L3,7
L4,5
L6
L8
L9,11
L10
SW1
T1
T2-4
SEMICONDUCTORS - continued.
Transistor,NPN,TO-92 case,2N3903
Transistor,PNP,TO-92 case,2N3905
Linear mode RWM controller,16-pin DIP,Silicon General SG3846N or equiv.
Photo-coupled isolator,6-pin DIP,General Electric 4N35 or equiv.
Linear quad fault monitor, 16-pin DIP,Silicon General SG3548N or equiv.
Linear switching regulator,5-pin TO-220 package,
Linear Technology LT1074CT or equiv.
Linear switching regulator,64V/5A,5-terminal TO-220 package,
Linear Technology LT1074HVCT or equiv.
MISCELLANEOUS COMPONENTS
Fuse,3AG slow-blow,250V,current rating dependent upon model:
RFL 9125B 24DCPS: 3A,Littelfuse 313003 or equiv.
RFL 9125B 48DCPS: 2A,Littelfuse 313002 or equiv.
RFL 9125B 125DCPS: 1A,Littelfuse 313001 or equiv.
Choke,high-current,12mH,4.5A,10%,40 MHz series resonant frequency,
Caddell-Burns 6860-02 or equiv.
Inductor,powerline,10mH,Renco RL-1283-10 or equiv.
Inductor,powerline,25mH,Pulse Engineering 92100 or equiv.
Choke,swingductor,100mH,5A,radial leads,Renco RL-1386-1-100 or equiv.
Inductor,powerline,55mH,Pulse Engineering 92116 or equiv.
Inductor,powerline,10mH,Renco RL-1284-10 or equiv.
Choke,swingductor,220mH,4.5A,radial leads,Renco RL-1386-1-220 or equiv.
Switch,rocker,SPST,marked,high inrush current
Transformer,input,voltage dependent upon model:
RFL 9125B 24DCPS: 24V
RFL 9125B 48DCPS: 48V
RFL 9125B 125DCPS: 125V
Transformer,current-sense,one-turn primary,100-turn secondary,
Pulse Engineering 67100 or equiv.
21562
21564
0620 326
47104
0620 325
0620 328
0620 337
6607
7549
6645
30436
30063
30064
30061
30068
30059
30062
30441 1
99548
99549
99551
101653
