LASER UNIT
3-23
Replacement
Adjustment
3.10.3
POLYGON MI
RROR MOTOR
1.
Laser unit (
☛
3.10.2)
2.
Laser unit cov
er [A] (
!
x
4, 2 hooks)
3.
Po
lygon m
irror m
otor [
B] (
!
x4,
"
x1)
4.
After repl
acing the m
otor, do the
image adjus
tment. (
☛
3.2
1)
B004R903.
W
MF
B004R201.
W
MF
B004R202.
W
MF
[A]
[B]
[B]
– 45 cpm ma
chine–
– 35 cpm ma
chine–
99
101
