26 January, 2001 DIP SWITCHES
5-73
Service
Tables
5.6 DIP SWITCHES
Controller: DIP SW2
DIP SW No. ON OFF
1 IC Card Boot System ROM Boot
2
3
4
Keep at “OFF”
I/O Board: DIP SW101
DIP SW No. Function ON OFF
1 Copy Speed 35 cpm (180 mm/s) 45 cpm (230 mm/s)
2 Jam Detection
(see Note)
Off On
3 SC Generation Disabled Enabled
4 Not used OFF (Do not change)
5 Not used OFF (Do not change)
6
7
Destination OFF Japan
OFF
ON North America
OFF
OFF Europe
ON
ON Not used
ON
8 Not used OFF (Do not change)
NOTE: Disabling jam detection is effective only for the main machine (not for the
options).
