SERVICE PROGRAM MODE 26 January, 2001
5-48
Test Pattern Table: SP2-902-3 Printing Test Patterns
No. Test Pattern No. Test Pattern
0 None 20 Horizontal Line (1-dot) (Reversed LD1, LD2)
1 Vertical Line (1-dot) 21 Grid Pattern (1-dot) (Reversed LD1, LD2)
2 Horizontal Line (1-dot) 22 Grid Pattern (1-dot pair) (Reversed LD1, LD2)
3 Vertical Line (2-dot) 23 Independent Pattern (1-dot) (Reversed LD1, LD2)
4 Horizontal Line (2 dot) 24 3 Grayscale
5 Grid Pattern (1-dot) 25 Grayscale (Horizontal)
6 Grid Pattern (1-dot pair) 26 Grayscale (Vertical)
7 (not used) 27 Grayscale (Vertical/Horizontal)
8 (not used) 28 Grayscale (Grid)
9 Full Dot Pattern 29 Grayscale (Horizontal Extension)
10 Black band 30 Grayscale (Vertical Extension)
11 Trimming Area 31 Grayscale (Horizontal Margin)
12 Trimming Area (2-dot) 32 Grayscale (Vertical Margin)
13 Argyle Pattern 33 Grayscale (Vertical/Horizontal Margin)
14 Argyle Pattern (2-dot_) 34 Grayscale (Horizontal Extension Margin)
15 Hound’s Tooth Check (2-dot
Horizontal)
35 Grayscale (Vertical Extension Margin)
16 Checker Flag Pattern 36 White Pattern
17 Point Black Pattern 37 Grid (1-dot pair) (OR Outside Data 1)
18 Black Band (Vertical) 38 Trimming Area (OR Outside Data)
19 Independent Pattern (4-dot)
