SERVICE PROGRAM MODE 26 January, 2001
5-42
SP7 Mode Number Function and [Setting]
7401* Total SC Counter Displays the total number of service calls that
have occurred. Display range: 0000~9999
7403* SC History
1*
Latest
2*
Latest 1
3*
Latest 2
4
*
Latest 3
5*
Latest 4
6*
Latest 5
7
*
Latest 6
8*
Latest 7
9
*
Latest 8
10*
Latest 9
Displays the most recent service calls successive
groups of 10.
7502* Total Paper Jam Counter Displays the total number of copy jams.
Display range: 0000~9999
7503* Total Original Jam Counter Displays the total number of original jams.
Display range: 0000~9999
7504* Paper Jam Counter by Jam
Location
Displays the total number of copy jams by
location.
Display range: 0000~9999
A “Paper Late” error occurs when the paper fails
to activate the sensor at the precise time. A
“Paper Lag” paper jam occurs when the paper
remains at the sensor for longer than the
prescribed time.
Paper Late
Error No.
Paper Lag
Error No.
Error
1* At Power On
3* 1st Paper Feed Sensor
4* 2nd Paper Feed Sensor
5* 3rd Paper Feed Sensor
6* 4th Paper Feed Sensor
7* 57* LCT Tray Relay Sensor
8* 58* Transport sensor 1
9* 59* Transport sensor 2
10* 60* Transport sensor 3
61* Transport sensor 4
13* 63* Registration Sensor
14* 64* Fusing Exit Sensor
16* 66* Exit Entrance Sensor
17* 67* Relay Sensor 1 (option)
18* 68* Relay Sensor 2 (option)
19* 69* Duplex Entrance Sensor
23* 73* Duplex Exit Sensor
24* 74* 1-Bin Tray Sensor
25* Finisher Entrance
26* Finisher Proof Tray
27* Finisher Shift Tray
