SERVICE PROGRAM MODE 26 January, 2001
5-56
ARDF Output Check: SP6-008)
1. Open SP mode SP6-008.
2. Select the SP number that corresponds to the component you wish to check.
(Refer to the table below.)
3. Press On then press Off to test the selected item. You cannot exit and close
this display until you click Off to switch off the output check currently executing.
No. Description
1 Feed Motor (Forward)
2 Feed Motor (Reverse)
3 Drive Motor (Forward)
4 Inverter Motor (Forward)
5 Inverter Motor (Reverse)
6 Feed Clutch
7 Inverter Solenoid
8 Pick-up Motor (Forward)
9 Pick-up Motor (Reverse)
5.1.6 SMC PRINT OUT LISTS: SP5-990
1. Open SP mode 5-990 and select the number corresponding to the list that you
wish to print.
SMC (System Parameter and Data Lists)
1
All Data List
2
SP Mode Data List
3
UP Mode Data List
4
Logging Data List
5
Self-Diagnostics Results List
7
NIB Summary
21 Copy UP Mode List
22 Scanner SP Mode List
23 Scanner UP Mode List
2. Press ' and then press Yes to confirm the selection of the list that you want to
print.
3. Press Copy Window to return to the copy window.
4. Select the paper size and press Start ( twice to print the list.
5. After printing the list, press SP Mode (highlighted) to return to the SP mode
display.
6. Press Exit twice to close the SP Mode screen and return to copy mode.
