SCANNER UNIT
26 January, 2001
3-12
3.9.5
ORIGINAL
SIZE SENSORS
1. ARDF
(
☛
3.9.1)
2.
Exposure g
lass (
☛
3.9.2)
3. Lens
block
(
☛
3.9.4)
4.
Origi
nal size sensor [A] (
!
x1,
"
x1)
5.
Origi
nal size sensor [B] (
!
x1,
"
x1)
6.
Origi
nal size sensor [C] (
!
x
1,
"
x1
)
B004R958.
W
MF
[A]
[B]
[C]
88
90
