PRINTER ENGINE SERVICE MODE 17 January, 2003
5-80
5.4.3 OUTPUT CHECK TABLE
CH: Charge
PF: Paper Feed
TS: Toner Supply
CW: Clockwise
CCW: Counterclockwise
MB: 4-bin Mailbox
DI: Duplex Inverter
SP5-
804-XXX
Description
1 Lift M UP (1) Tray 1 Lift Motor / UP
2 Lift M DOWN(1) Tray 1 Lift Motor / DOWN
3 Lift M UP(2) Tray 2 Lift Motor / UP
4 Lift M DOWN(2) Tray 2 Lift Motor / DOWN
5 By-pass CL By-pass Feed Clutch
6 Pick-up SOL Pick-up Solenoid
7 PF CL (1) Paper Feed Clutch - Tray 1
8 PF CL (2) Paper Feed Clutch - Tray 2
9 PF GRP SOL Grip Roller Release Solenoid
10 Regist CL Registration Clutch
11 Junction SOL Exit Junction Gate Solenoid
12 Oil Supply SOL Oil Supply Unit Solenoid
13 Fusing CL Fusing Clutch
19 K Dev CL Development Unit Clutch - K
20 C Dev CL Development Unit Clutch - C
21 M Dev CL Development Unit Clutch - M
22 Y Dev CL Development Unit Clutch - Y
23 K Dev M H Development Motor - K / High Speed
24 K Dev M M Development Motor - K / Middle Speed
25 K Dev M L Development Motor - K / Low Speed
26 K Dev M Card Black Development Motor - Thick paper
27 FC Dev M H Color Development Motor - 185mm/s
28 FC Dev M M Color Development Motor - 125mm/s
29 FC Dev M L Color Development Motor - 62.5mm/s
30 TS CL [Y] Toner Supply Clutch for Yellow
31 TS CL [M] Toner Supply Clutch for Magenta
32 TS CL [C] Toner Supply Clutch for Cyan
33 TS CL [K] Toner Supply Clutch for Black
34 Valve SOL [K] Air Flow Valve solenoid for Black
35 Valve SOL [C] Air Flow Valve solenoid for Cyan
36 Valve SOL [M] Air Flow Valve solenoid for Magenta
37 Valve SOL [Y] Air Flow Valve solenoid for Yellow
38 Toner Sply Mt1 Toner Supply Motor 1 - yellow and magenta
39 Toner Sply Mt2 Toner Supply Motor 2 - cyan and black
40 Air Supply [Y] Air Pump Motor and Valve for Yellow
41 Air Supply [M] Air Pump Motor and Valve for Magenta
42 Air Supply [C] Air Pump Motor and Valve for Cyan
43 Air Supply [K] Air Pump Motor and Valve for Black
44 T End Sens [Y] Toner End Sensor - Y
To Next Page
