17 January, 2003 FUSING
3-37
Replacement
Adjustment
3. Fuse [A] (! x 3)
3.9.10 PRESSURE ROLLER FUSING LAMP
1. Fusing belt unit (☛ 3.9.5)
2. Pressure roller fusing lamp [A] (! x 2)
G080R715.WMF
G080R710.WMF
[A]
[A]
